Culligan E2 Plus Series - Page 11

RO Installation 7
Cat. No. 01023094
MODEL E2-5 Plus
MODEL E2-6 Plus
CENTER PORT
OF END CAPS.
OFF-CENTER PORT
OF END CAPS
CENTER PORT
OF END CAPS.
OFF-CENTER PORT
OF END CAPS
OFF-CENTER PORT
OF END CAPS
OFF-CENTER
PORT OF END
CAPS
Figure 4. E2 Plus Module Tubing, five or six membranes.
WARNING! The system must be grounded. An improperly grounded unit could cause injury
from electrical shock!
