SETTINGS 11
Note that the silver half of the time-of-day dial designates the daytime hours, while the black half designates the
night-time hours.
GUEST CYCLE
An extra recharge can be initiated any time extra soft water is required by pushing the Manual Recharge lever (M)
in the direction of the arrow, then releasing. The unit will still recharge at its regular frequency as determined by
the meter device. On models with meter control, the red button (X) must also be pushed briefly before the recharge
cycle can begin.
SERVICE POSITION
The timer assembly is in the service position when the toothless notch in the cam gear is over the teeth on the idler
gear (L). The timer will return to this position after each recharge (Fig. 8).
TIME CLOCK SETTINGS
To set the Mark 89 and 812 water conditioner for optimal performance, determine the hardness of the water along
with the number of people in the household. Refer to Table 2. Locate the row corresponding to the number of
people in the home and move across to the appropriate hardness column. The number in the shaded region is the
salt dosage. The other number is the frequency of regeneration.
SALT DOSAGE
To set the salt dosage, refer to Fig. 8. Loosen screw (A) and rotate outer dial until the salt dosage dial line up with
the indicator mark (D). Tighten screw (A).
*In household application, not recommended for over 10 people because of pressure drop limitations.
TABLE 2A — CULLIGAN MARK 89 WATER CONDITIONER SALT DOSAGE — FREQUENCY
Water
*Persons Usage
in 0-7 8-14 15-21 22-28 29-35 36-42 43-49 50-56 57-63 64-75 Gal. (Litres)
Household (0-120) (121-240) (241-360) (361-480) (481-600) (601-720) (721-840) (841-960) (961-1080) (1081-1280) per day
11 12233 336
2 150(570)
5575656895
11 22336 666
3 225(850)
5757695568
12 23366 666
4 300(1135)
55769568912
12 33666 66
5 375(1420)
55595791213
12 36666
6 450(1705)
79856912
23 6666
7 525(1990)
5555812
23 666
8 600(2270)
57569
23 666
9 675(2555)
595713
23 66
10 750(2840)
51259
