Control Valve Parts List
01-0037-43 Control Valve Assembly - Mark 89, TC 01-0037-44 Control Valve Assembly - Mark 812, TC 01-0137-03 Control Valve Assembly - Mark 89, SM 01-0137-04 Control Valve Assembly - Mark 812, SM
1 00-4498-65 Control Valve 2 00-4481-26 Rear Body Plug
‡3 00-4449-14 O-Ring
4 00-4481-28 Retainer, Rear Body Plug
‡5 00-4468-35 Drain Elbow Assembly w/O-Ring
6 00-3184-78 Screw
‡7 01-0130-83 Seal Pack Assembly
8 00-4473-87 Retainer, Drain Elbow 9 00-4010-22 Eductor Port Cover
‡10 00-4457-97 Gasket
11 00-4517-01 Clamp
17 01-0126-49 Follower 18 01-0126-48 Yoke 20 01-0126-47 Bracket 22 00-3185-50 Screw 26 00-3183-54 Nut 27 00-4452-21 Bellcrank
‡28 01-0136-03 Drive Motor & Bracket Assembly, 120V/60 Hz
29 00-4452-46 Roll Pin 30 00-4435-59 Roll Pin 31 00-4010-40 Switch Bracket 32 00-4452-72 Barrier
‡33 00-4452-44 Switch
34 00-3183-43 Washer 35 00-4486-86 Screw 37 01-0130-31 Cam 38 01-0129-28 Spacer 40 00-4486-59 Retaining Ring 41 00-3184-55 Screw 42 00-3184-52 Screw 43 01-0083-40 Control Back Plate
‡44 00-4429-21
Timer Mechanism, 6 Day, 120V/60 Hz - TC Models
61 00-3318-78 Screw 62 00-4444-53 Strain Relief Adapter 63 00-4444-52 Strain Relief
64 00-4429-84 Power Cord 65 00-3318-48 Terminal Strip 66 00-4442-84 Screw 67 00-4015-67 Clip 68 01-0017-84 Screw 80 00-4429-29 Label 81 00-4022-01 Screw 83 01-0128-09 Control Cover 84 00-4457-80 Cover Plate 85 01-0046-89 Cul-Flo Bracket 86 00-3183-83 Screw
‡98 00-4012-48 Eductor w/O-Rings
99 00-4452-69 Eductor Screen
‡100 00-3084-38 O-Ring ‡101 00-3084-37 O-Ring
102 00-4432-91 Connector Brine Line 103 00-3031-93 Nut, PP, 0.312" 104 00-3031-92 Insert, PP, 0.312"
‡105 00-4479-87 O-Ring ‡106 01-0136-06 Eductor Sleeve and Eductor Piston Assembly
107 00-4479-86 O-Ring 108 00-3084-07 O-Ring 120 01-0082-55 Meter Mounting Bracket
‡121 01-0101-27 Circuit Board - 120 Volt
‡156 00-4460-38 Eductor Nozzle - Blue, 9" Tanks
00-4460-39 Eductor Nozzle - Light Brown, 12" Tanks
157 00-3316-45 Backwash Flow Restrictor, #2, Brown, 9" Tanks
00-3316-36 Backwash Flow Restrictor, #3, Green, 12" Tanks
178 01-0051-30 Bracket 197 00-4462-96 Decal, Mark 89
00-4462-97 Decal, Mark 812
223 00-4486-87 Screw
* 01-0051-26 Noise Suppressor - SM Models * 01-0079-01 Wire Harness, Circuit Board - SM Models * 01-0079-02 Wire Harness, Regen. Switch - SM Models * 01-0112-79 Flow Meter Assembly - SM Models * 00-4029-54 Cam Wire Harness - TC Models * 00-4029-55 Cam Wire Harness - SM Models * 00-3308-32 Hat Screen - SM Models
Item Part No. Description Item Part No. Description
‡ Recommended Spare Parts * Not Illustrated
CONTROL VALVE PARTS LIST 21
