24 CULLIGAN
®
MARK 89 AND 812 WATER CONDITIONER
Item Part Number Description
— 00-4418-88 Brine Valve Assembly
— 00-4011-41 Brine Valve Assy., Brine Tank, 160 lb.
1 00-3031-93 Plastic Nut, 5/16-inch
2 00-3031-92 Plastic Insert
3 00-4407-96 Refill Cap
‡4 00-3084-07 O-ring
‡5 00-4016-22 Flow Restrictor, No. 5, 0.45 gpm (170 lpm)
6 00-3400-14 Stem Seat Assy., 250 lb. (114 kg) & 375 lb.
(170 kg) (US) & 350 lb. (159 kg) (Canadian)
7 00-4407-95 Refill Body
‡8 00-3325-28 Hat Screen
9 00-2234-35 Plastic Pipe, 1/4-inch NPT x 35 inches long,
250 lb. (114 kg) & 375 lb. (170 kg) (US) &
350 lb. (159 kg) (Canadian)
10 00-3047-03 Float Retainer (2 required)
11 00-3047-18 Float Weight, Stainless Steel (2)
12 00-4448-73 Float
13 00-3320-72 Screen Top Seal
14 00-4446-64 Filter Screen Cap
‡15 00-4444-96 Stem Seat
16 00-4473-92 Insert
17 00-4477-81 Air Eliminator Ball
‡18 00-3048-04 Ball Seat
19 00-5418-21 Float Valve Body with Ball Seat
00-5418-34 Float Valve Body with Ball Seat, 150 lb.
Brine Tank
20 00-3045-37 Brine Valve Chamber, 250 lb. (114 kg) &
375 lb. (170 kg) Salt Storage Tank (US)
00-4413-92 Brine Valve Chamber, 160 lb. (Shown)
† Brine Valve Chamber, 350 lb. (159 kg)
(Canadian)
21 00-3046-06 Cap, Brine Valve Chamber
* 00-3184-92 Screw, Brine Valve Chamber (Canadian)
#10 - 16 x 1/2-inch TRS HD PHIL
* 00-3306-29 Connector Spacer, Brine Valve Chamber
(Canadian)
* 00-4463-88 Screw, St. Steel, Brine Valve Chamber (US)
* 00-4463-89 Nut, St. Steel, Brine Valve Chamber (US)
* Not Illustrated
† Replace with 00-3045-15 and relocate spacer
‡ Recommended Spare Parts
Brine Valve & Parts List
