13
ASSEMBLY & OPERATING INSTRUCTIONS – 254 CONDUIT BENDER
(CONTINUED)
18. Once the hydraulic pressure is released and
the hydraulic cylinder has retracted, remove
the saddle pin spring clip. Remove the saddle
pin and saddle. Next, remove the bent conduit
from the bending set-up.
17. When the desired degree of bend is
complete, rotate the pump valve lever
to the open position to release the
hydraulic pressure and the hydraulic
cylinder will retract.
