Currys Essentials C16LDIB11 - Front; Right Side View and Controls

GB
7
Preparation
Front / Right Side View and Controls
Item Description
1 POWER LED
Illuminates green when the TV is turned on. Illuminates red when the TV is in standby
mode. The LED will flash green and red when the timer programming has started in
the standby mode.
2 IR (Infrared Receiver)
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
3 INPUT
Press to select among different input signal sources:
DTV / ATV / SCART / YPbPr / PC / HDMI1 / HDMI2 / AV / USB.
Confirmed the selection on OSD menu.
4 MENU Displays the OSD (on screen display) menu.
5 CH + / – Selects a channel or select a sub-menu from the OSD menu.
6 VOL + / –
Adjusts the volume.
Selects and adjusts a setting in the OSD menu.
7
Switches the TV on from standby mode.
Switches the TV back to standby mode.
3
4
6
7
5
1 2
