4 — MONITOR MENU
pg. 27
Return to TOC 1212 & 1212P Manual - Sep 2019
4 — MONITOR MENU
rough its Monitor menu, the 1311 programmer provides access to real-time data during vehicle
operation. This information is helpful during diagnostics and troubleshooting, and also while
adjusting programmable parameters.
MONITOR MENU
VARIABLE DISPLAY RANGE DESCRIPTION
Temp –55 – +127 °C Controller’s internal temperature.
Battery Voltage 0–38.2 V Battery voltage.
Motor Voltage –27.4 – +27.4 V Voltage drop between the motor terminals.
Motor Thermal Cutback 0–100 % Current cutback during motor over-temperature, as a percentage of max
current. 100% = no cutback.
Armature Current –90 – +90 A Measured motor armature current.
Current Limit 0–90 A Ultimate current limit of the controller, taking into account boost mode,
thermal protection, etc.
Resistance 0–854 mW Measured system resistance,when the motor is stalled.
Throttle 0–100 % Available throttle input.
Speed Limit Pot 0–100 % Available speed limit pot input.
Mode Input On/Off Status of the mode switch (at J1-4).
Reverse Input On/Off Status of the reverse switch (at J1-12).
Inhibit On/Off Status of the speed inhibit switch (at J1-6).
EMR Input On/Off Status of the emergency reverse switch (belly button switch).
Push Input On/Off Status of the push switch (at J1-14).
Main Contactor On/Off Status of the main contactor driver.
Brake On/Off Status of the EM brake driver.
BDI 0–100 % Status of battery capacity.
Drive Time 0–65535 hours Hours of operation since the hourmeter was last reset (Reset Drive Time = On).
