Curtis 1232E/34E/36E/38E & 1232SE/34SE/36SE Manual, os 30
77
24 NOVEMBER 2015
4a — MONITOR MENU
Monitor Menu: OUTPUTS
DISPLAY
VARIABLE RANGE DESCRIPTION
Analog Out 0.00 – 10.00 V Voltage at Analog output (pin 30).
Analog_Output 0 – 32767
0x321D 0x00
Digital Out 6
On / Off Digital Out 6 output on or off (pin 19).
Dig6_Output On / Off
System_Flags1 [Bit 3]
0x322B 0x00
Digital Out 7
On / Off Digital Out 7 output on or off (pin 20).
Dig7_Output On / Off
System_Flags1 [Bit 4]
0x322B 0x00
Driver 1 PWM
0 – 100 % Driver 1 PWM output (pin 6).
PWM1_Output 0 – 32767
0x321F 0x00
Driver 2 PWM
0 – 100 % Driver 2 PWM output (pin 5).
PWM2_Output 0 – 32767
0x3220 0x00
Driver 3 PWM
0 – 100 % Driver 3 PWM output (pin 4).
PWM3_Output 0 – 32767
0x3221 0x00
Driver 4 PWM
0 – 100 % Driver 4 PWM output (pin 3).
PWM4_Output 0 – 32767
0x3222 0x00
PD PWM
0 – 100 % Proportional driver PWM output (pin 2).
PD_Output 0 – 32767
0x321E 0x00
PD Current
0.00 – 2.00 A Current at proportional driver (pin 2).
PD_Current 0 – 607
0x321C 0x00
5 Volts
0.00 – 6.25 V Voltage at +5V output (pin 26).
Five_Volts_Output 0 – 1023
0x3202 0x00
12 Volts
0.00 – 12.00 V Voltage at +12V output (pin 25).
Twelve_Volts_Output 0 – 768
0x3522 0x00
