TURF TRUCKSTER
Item Part No. Qty. Description Serial Numbers/Notes
1
N/S 1 Engine, Perkins Model 403C-11 Spec HH70581U
842553 1 • Engine Oil Filter
185086321 1 • Starter Order directly from Perkins
2 843760 1 Bracket, Hydraulic Pump
3 844272 1 Mount, Right Side Engine
4 838440 8 Screw, M12-1.25 x 25 mm Flange
5 120166 8 Lockwasher, 1/2
6 REF 1 Pump, Hydraulic See 34.1
7 800073 1 Carriage Bolt, 3/8-16 x 1-1/4”
8 306981 2 Flat Washer, 3/8
9 120177 2 Lockwasher, 3/8
10 306562 2 Nut, 3/8-16 Hex
11 REF 1 Pump, Power Steering See 17.1
12 844268 1 Bracket, Rear Power Steering Mount
13 452395 2 Screw, M8-1.25 x 80 mm Flange
14 452388 5 Screw, M8-1.25 x 20 mm Flange
15 450453 7 Nut, M8-1.25 Flange
16 893633 1 Alternator
17 844270 1 Bracket, Front Alternator Mount
18 844271 1 Bracket, Rear Alternator Mount
19 600981 1 Bracket, Alternator Adjusting
20 311213 1 Screw, 3/8-16 x 3” Flange
21 548804 1 Nut, 3/8-16 Flange
22 306416 1 Screw, 5/16-18 x 1” Hex Head
23 306325 3 Lockwasher, 5/16
24 452390 3 Screw, M8-1.25 x 30 mm Flange
25 452394 2 Screw, M8-1.25 x 70 mm Flange
26 842996 1 Pulley, 4”
27 306835 1 Screw, 3/8-16 x 1-1/4” Hex Head
28 894645 1 Ring, Pressure Plate
29 22400-85141 1 Disc, Clutch Included with Transmission
30 22100-85200 1 Cover, Clutch Included with Transmission
31 839752 3 Dowel Pin, 8 x 18 mm
32 09111-08035 2 Screw, M8-1.25 Special Included with Transmission
33 841966 1 Belt, Hydraulic Pump
34 600997 1 Belt, Alternator - Power Steering 48”
35 103867 1 Flat Washer, 3/8
36 600993 1 Pulley, 5.8” Power Steering
37 REF 1 Throttle Bracket
38 821893 AR Trim, Push On
★ Indicates hardware included with Engine.
