Cushman 898628 - Engine Speed Control

84
> Change from previous revision
2
3
5
6
7
8
9
10
12
1
1
13
14
4
Part of
Engine
15
1
16
17
TURF TRUCKSTER
25.1 Engine Speed Control
Serial No. 84043 All
Serial No. 84044 All
Item Part No. Qty. Description Serial Numbers/Notes
1
2703683 1 Throttle Cable See 3.1 for other end of cable
2 844130 1 Cable, Governor Control See 3.1 for other end of cable
3 894591 1 Bracket, Throttle See 23.1 for Mounting Location
4 844274 1 Lever, Governor
5 835271 1 Nut, 1/4-20 Lever Pivot
6 130728 1 Nut, 1/4-20 Hex Jam
7 840473 1 Spring, Governor Lever
8 812444 1 Clevis Pin, 5/16 x 3/4”
9 103867 1 Flat Washer, 5/16
10 821164 1 Hair Pin
11 842785 1 Spring, Idle Return
12 800271 1 Screw, #10-24 x 1/2” Pan Head
13 120052 1 Lockwasher, #10
14 111898 1 Clamp, Cable
15 831888 1 Swivel
16 831889 1 Washer, Swivel
17 831890 1 Screw, Swivel Throttle Cable
