TURF TRUCKSTER
Item Part No. Qty. Description Serial Numbers/Notes
4115000 1 Governor
1
111812 1 • Yoke, Spool
2 111814 1 • Washer, Thrust
3 111816 1 • Washer, Thrust
4 111817 1 • Spool, Governor
5 112840 1 • Bearing, Thrust
6 130728 1 • Nut, 1/4-20 Hex Jam
7 111813 1 • Seal, Shaft
8 160410 1 • Carrier & Weights
9 302288 2 • Screw, 1/4-20 x 1” Hex Head
10 306396 2 • Lockwasher, 1/4
11 306506 2 • Lockwasher, #6
12 306915 2 • Screw, #6-32 x 5/16” Machine
13 603102 1 • Roll Pin, 1/8 x 3/4”
14 548325 1 • Ring, Retaining
15 800227 2 • Plug, 1/8 NPT
16 800558 1 • Set Screw, 3/8-16 x 5/16”
17 833056 1 • Gasket, Governor
18 833102 1 • Seal, Oil
19 835271 1 • Nut, Governor Arm
20 843537 1 • Bracket, Governor Knee
21 4114867 1 • Head, Governor
22 894471 1 • Reservior, Governor
23 833103 1 • • Bearing, Needle
24 4119678 1 • Shaft, Governor Complete
25 4117681 1 • • Shaft, Governor
26 833104 1 • • Ring, Retaining
27 833345 1 • • Bearing, Ball
28 2700525 1 • Lever, Governor Control
29 306396 2 Lockwasher, 1/4
30 894435 1 Bracket, Throttle
31 894434 1 Arm
32 843866 1 Bushing, Governor
33 302288 1 Screw, 1/4-20 x 1” Hex Head
34 00414-G5 2 Screw, Hex Head
35 308020 1 Flat Washer, 1/4
36 833101 1 Spring, Extension
37 111898 2 Clamp, Cable
38 120052 1 Lockwasher, #6
39 306514 1 Screw, #10-32 x 1/2” Truss
40 844130 1 Governor Cable See 3.1
41 817104 1 Stop, Wire
42 800024 1 Screw, 1/4-20 x 1-1/2”
43 306375 1 Nut, 1/4-20 Hex
