103
> Change from previous revision
TURF TRUCKSTER
Item Part No. Qty. Description Serial Numbers/Notes
1
450452 3 Nut, M6-1 Hex Flange
2 452378 2 Screw, M6-1 x 20 mm Hex Flange
3 889673 1 Solenoid, Starter
120052 2 • Lockwasher, #10
132520 2 • Nut, #10-32 Hex
306325 2 • Lockwasher, 5/16
306932 2 • Nut, 5/16-18 Hex
4 844167 1 Bracket, Horn, Brake Fluid Reservior
5 800943 15 Screw, #10-16 x 3/4” Thread Cutting
6 886425 1 Horn
7 800934 3 Screw, M6-1 x 16 mm Hex Flange
8 894266 1 Harness, Main See 48.1
9 843942 1 Socket, 12V Accessory Plug
10 4116941 1 Panel, Instrument with Tachometer
11 890000 1 Buzzer, High Temperature
Located inside front clip, behind
dash panel
12 831225 3 Clamp, Wire Harness
13 306419 2 Screw, 1/4-20 x 1/2” Hex Head
14 306488 1 Lockwasher, 1/4 External Tooth
15 828231 1 Insulator
16 548175 1 Flat Washer, 1/4
17 894596 1 Positive Battery Cable
18 884513 1 Negative Battery Cable Battery to Transmission
19 306325 1 Lockwasher, 5/16
20 450324 1 Nut, M8-1.25 Hex
21 892811 1 Cable, Ground Transmission to Right Frame Rail
22 450453 1 Nut, M8-1.25 Hex Flange
23 452388 1 Screw, M8-1.25 x 20 mm Flange
24 841895 1 Cover, Positive Battery Terminal
To Next Page
