TURF TRUCKSTER
Item Part No. Qty. Description Serial Numbers/Notes
1
REF 1 Front Suspension See 14.1, 15.1 and 16.1
2 452415 8 Screw, M12-1.75 x 80 mm Flange
3 450454 8 Nut, M10-1.5 Hex Flange
4 4139806G03 2 Wheel and Tire, Multi Rib Standard
4 4139806G03 2 Wheel and Tire, Turf Master Optional
4 4139806G03 2 Wheel and Tire, USA Trail Optional
4139793 1 • Rim, 10.00 x 7” Five Bolt 3.94” Bolt Circle
N/S 1 • Tire, 20 x 10.00 - 10 Multi Rib Used on 4139806G03, Obtain Locally
N/S 1 • Tire, 20 x 10.00 - 10 Turf Master Used on 4139806G01, Obtain Locally
N/S 1 • Tire, 20.5 x 8.00 - 10 USA Trail Used on 4139806G02, Obtain Locally
886735 1 • Valve Stem
5 800909 2 Nut, M12-1.5 Wheel Lug
6 REF 1 Panel, Console See 4.1
7 800026 7 Screw, 1/4-20 Truss Head
8 894232 1 Cover, Left Side Engine
9 452398 18 Screw, M10-1.5 x 20 mm Flange
10 450454 20 Nut, M10-1.5 Hex Flange
11 893488 1 Fender, Right Side
12 893487 1 Fender, Left Side
13 452399 2 Screw, M10-1.5 x 25 mm Flange
14 893602 1 Stop and Tail Light
822049 1 • Bulb, No. 1157
312288 2 • Lens, Screw
829099 1 • Lens and Gasket Includes License Illuminator Lens
15 548910 2 Nut, 1/4-20 Serrated Flange
16 894313 1 Harness, Taillight Wire
17 4117153.7 1 Support, Fuel Tank
18 800177 1 Screw, 5/16-18 x 3/4” Truss
19 548911 1 Nut, 5/16-18 Hex Flange
20 800930 1 Screw, M8-1.25 x 16 mm Flange
21 450453 1 Nut, M8--1.25 Hex Flange
22 REF 1 Radiator Support
23 REF 1 Frame, Lower ROPS and Platform See 12.1
To Next Page
