If the mobile scaffold tower is placed against a wall, do not remove the outrigger/arch, but
turn it parallel to the wall. If the mobile scaffold tower is placed at an angle, remove the inner
outrigger/arch, and turn the outer two parallel to the wall.
expansion arch
option: brace
outrigger
Fig.3
Fig.4
Fig.5
