Cutler-Hammer Digitrip OPTIM 550 - Typical System Configurations

I.B. 29C891B
Page 6
Effective 11/98
Figure 1-9 Typical System Configurations
Master
Computer
Breaker
Interface
Module
Shielded
Twisted
Pair
SPB
Circuit
Breaker
with
OPTIM
DSII
Circuit
Breaker
with
OPTIM
Series C
R-Frame
MCCB
with
OPTIM
To Other IMPACC
Compatible Devices
PONI
OPTIMizer
Series C
N-Frame
MCCB
with
OPTIM
Series C
L-Frame
MCCB
with
OPTIM
Circuit
Breaker
with
RMS 810
or 910
Series C
F-Frame
MCCB
ES
IQ Energy Sentinel
Shielded
Twisted
Pair
PONI Module
(Required for IMPACC
Network Communications
to Master Computer)
Shielded
Twisted
Pair
➁ ➂
➃
OPTIMizer
➀
➀
OPTIMizer
➀
OPTIMizer
➀
OPTIMizer
➀
Series C
K-Frame
MCCB
with
OPTIM
OPTIMizer
➀
NOTES
➀
OPTIMizer Hand Held
Programmer compatible only
with OPTIM Trip Units
➁ Can monitor up to 50 com-
patible devices.
➂ Circuit breakers with OPTIM
Trip Units can be directly
connected to a master com-
puter, and do not have to be
connected through the BIM.
➃ Universal IQ Energy Sentinel
also compatible with Breaker
Interface Module.
CONFIGURATIONS 1 + 2
Network Configuration —
Breaker Interface Module with
Master Computer as Master
Device
CONFIGURATION 1
Sub-Network Configuration —
Breaker Interface Module
Functioning as Master Device
CONFIGURATION 2
Master Computer and IMPACC
Software
