CyberPower CP900EPFCLCD User Manual

8
(Note: The OUTPUT meter shows the status of the battery backup outlets in terms of load,
frequency, and voltage.)
11. INPUT meter: This meter measures the AC voltage that the UPS system is receiving from the
utility wall outlet. The UPS is designed, through the use of automatic voltage regulation, to
continuously supply connected equipment with stable, 220/230 output voltage. In the event of a
complete power loss, severe brownout, or over-voltage, the UPS relies on its internal battery to
supply consistent 220/230 output voltage. The INPUT meter can be used as a diagnostic tool to
identify poor-quality input power.
12. EVENT: This meter records the number of power outages.
13. MUTE: This icon appears whenever the UPS is in silent mode. The buzzer does not beep during
silent mode until the battery reaches low capacity.
14. AVR (Automatic Voltage Regulation): This icon appears whenever your UPS is automatically
correcting low AC line voltage without using battery power. This is a normal, automatic operation
of your UPS, and no action is required on your part.
For more information about functions setup, please refer to the Function Setup Guide.
TECHNICAL SPECIFICATIONS
Model CP900EPFCLCD CP1300EPFCLCD CP1500EPFCLCD
Capacity (VA) 900VA/540W 1300VA/780W 1500VA/900W
Input
Frequency Range 50/60Hz +/- 3Hz (Auto-sensing)
AVR Function Yes
Output
On Battery Output
Voltage
230Vac +/-10%
On Battery Output
Frequency
50/60Hz +/-1%
Overload Protection On Utility: Circuit Breaker, On Battery: Internal Current Limiting
Surge Protection
Lightning / Surge
Protection
Yes
Network/ Phone/ Fax/
Modem Protection
RJ11/RJ45 ( One In/ One Out )
Operating Temperature
+32
°
F to 104
°
F ( 0
°
C to 40
°
C )
Physical
Total # of UPS outlets Schuko x 6
Maximum
Dimensions(LxWxH)
275 x 100 x 230 mm
370 x 100 x 265 mm
Weight (kg) 6.6kg 9.5kg 10.9kg
Battery
Battery Sealed Maintenance Free Lead Acid Battery

CyberPower CP900EPFCLCD Specifications

General

Waveform	Pure sine
Output power	540 W
UPS topology	Standby (Offline)
Input frequency	50/60 Hz
Maximum current	10 A
Surge protection	Yes
Country of origin	China
Audible alarm modes	Alarm when on battery, Low battery alarm, Overload alarm
Surge energy rating	405 J
Output power capacity	0.9 kVA
Power protection features	Over power, Over voltage, Overload, Short circuit
Surge protection features	Fax, Modem, Network, Telephone
Input operation voltage (max)	270 V
Input operation voltage (min)	170 V
Output voltage Total Harmonic Distortion (THD)	10 %
Interface	USB
Nominal input voltage	165-265 V
Nominal output voltage	230 V
Operating temperature (T-T)	32 - 104 °F
Compatible operating systems	Windows 7/Vista/XP/2000/Server 2003, Linux
Suitable for use in country/location	Europe
Power plug	C14 coupler
AC outlets quantity	6 AC outlet(s)
Modem (RJ-11) ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Form factor	Tower
Cable length	1.83 m
Display type	LCD
Certification	CE, EAC, RCM
Product color	Black
LED indicators	Operation
Housing material	Plastic
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 15000 m
Storage temperature (T-T)	15 - 45 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	8504408590
Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	8 h
Typical backup time at full load	1 min
Typical backup time at half load	7 min

Weight and Dimensions

Depth	230 mm
Width	100 mm
Height	275 mm
Weight	6600 g
Package depth	365 mm
Package width	195 mm
Package height	335 mm
Package weight	7800 g
