CyberPower OR1500LCDRTXL2U User Manual

TECHNICAL SPECIFICATIONS
Model OR1500LCDRTXL2U OR2200LCDRTXL2U
Capacity 1500VA / 1125W 2190VA / 1650W
Input Voltage or Utility 90V to 140V
Input Frequency 47 Hz ± 63 Hz (Auto-sensing)
On-Battery Output Voltage 120Vac ± 5%
Transfer Time 4 ms Typical
Max Load for UPS Outlets
(8 Outlets)
1500VA / 1125W 2190VA / 1650W
On-Battery Output
Wave Form
Simulated Sine Wave Form
Operating Temperature + 32°F to 104° F / 0° C to 40° C
Operating Relative Humidity 0 to 90% non-condensing
Size (L x W x H) 433 x 478 x 88 mm (2U Rack) / 17 x 18.8 x 3.5 in.
Net Weight 59.5 lbs. / 27 kg 66.1 lbs. / 30 kg
Battery Type CyberPower / RBP834 CyberPower / RBP844
Typical Battery
Recharge Time
8 hours
Typical Battery Life 3 to 6 years, depending on number of discharge/recharge cycles
Recommended Battery Sealed Maintenance Free Lead Acid Battery
Safety Approvals UL1778, CSA C22.2 No 107.3, FCC/DoC Class B
SYSTEM FUNCTION BLOCK DIAGRAM
Input Output
Battery Mode
Normal Mode
EMI
Filter
Surge
Suppressor
Inverter
Charger
AC / DC
Battery
AVR

CyberPower OR1500LCDRTXL2U Specifications

General

Output power	1125 W
Input frequency	- Hz
Surge energy rating	1840 J
Output power capacity	1.5 kVA
EMI/RFI noise filtering	Yes
Power protection features	Overload
Battery type	12V, 7AH
Management platform	SNMP, HTTP
Nominal input voltage	90-140 V
Nominal output voltage	120 V
AC outlet types	NEMA 5–15R
AC outlets quantity	8 AC outlet(s)
Modem (RJ-11) ports	2
USB 2.0 ports quantity	1
Form factor	Rackmount/Tower
Cable length	3 m
Display type	LCD
Certification	UL1778, cUL 107.3, FCC DOC Class B
Product color	Black
Rack capacity	2U
Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	8 h
Typical backup time at full load	7 min
Typical backup time at half load	18 min
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	0 - 90 %
Sustainability certificates	RoHS

Weight and Dimensions

Depth	477.52 mm
Width	431.8 mm
Height	88.9 mm
Weight	26988.7 g
