Technical Specifications
Switched Series (2U) Monitored Series (2U)
Model Name
PDU30SWT16FNET PDU30SWHVT16FNET PDU30MT16FNET PDU30MHVT16FNET
Input
Nominal Voltage 100-120V 200-240V 100-120V 200-240V
Frequency 50/60Hz
Derated Input Current 24A
Plug Type NEMA L5-30P NEMA L6-30P NEMA L5-30P NEMA L6-30P
Power Cord Type SR (10 AWG)
Power Cord Length 10 ft/3.05 m 12 ft/3.65 m
Output
Nominal Voltage 100-120V 200-240V 100-120V 200-240V
Derated Output Current 24A
Derated Output Current
(each bank)
20A 15A 20A 15A
Bank Number 2
Outlet Type NEMA 5-20R IEC-320 C13 NEMA 5-20R
IEC-320 C13*12/
IEC-320 C19*4
Outlet Number 16
Circuit Breaker Yes
Networking
Protocol Support TCP/IP, UDP, DHCP, SNMP, HTTP
Connectivity RJ45
Physical
Dimension (HxWxD) 3.5" x 17.05" x 4.41"/88mm x 433mm x 112mm
Environmental
Humidity 0 to 95% Non-condensing
Altitude 14700 ft/4500 m
Temperature 32
o
F to 104
o
F /0
o
C to 40
o
C
Safety Approvals
Certifications UL 60950-1, CSA C22.2, FCC Class A
Warranty
Product Warranty 2 years
Product Features (2U Series)
Front panel description
NEMA Type
IEC Type
A. Power Cord
B. AC Output Outlets
C. Input Circuit Breaker
D. Current Level
E. Input Voltage
F. Power
G. Load Indicator
H. Ethernet Port
I. Tx/Rx Indicator
J. Link Indicator
K. Outlet Indicator
(switched series only)
L. Serial/ ENVIROSENSOR Port
(RJ45 modular port)
M.Select Button
N. PDU Status Screen
O. Reset Button
Rear panel description
A. External Site Ground
