CyberPower PDU15SW8FNET User Manual

6
For more information on CyberPower products, visit www.CPSww.com
A. Power Cord
B. AC Output Outlets
C. Current Level
D. Input Voltage
E. Power
F. Load Indicator
G. Ethernet Port
H. Tx/Rx Indicator
I. Link Indicator
J. Outlet Indicator
(switched series only)
K. Serial /
ENVIROSENSOR Port
(RJ45 modular port)
L. Select Button
M. PDU Status Screen
N. Reset Button
A. Bracket Screw Hole
B. Keyhole Mount Peg
Screw Hole
Technical Specifications
Switched Series (0U 15A) Monitored Series (0U 15A)
Model Name
PDU15SWV16FNET PDU15MV16FNET
Input
Nominal Voltage 100-120V
Frequency 50/60Hz
Derated Input Current 12A
Plug Type NEMA 5-15P
Power Cord Type SR (14 AWG)
Power Cord Length 10 ft/3.05 m
Output
Nominal Voltage 100-120V
Derated Output Current 12A
Outlet Type NEMA 5-15R
Outlet Number 16
Networking
Protocol Support TCP/IP, UDP, DHCP, SNMP, HTTP
Connectivity RJ45
Physical
Dimension (HxWxD) 49" x 2.20" x 1.75"/1245mm x 56mm x 44mm
Environmental
Humidity 0 to 95% Non-condensing
Altitude 14700 ft/4500 m
Temperature 32
o
F to 104
o
F /0
o
C to 40
o
C
Safety Approvals
Certifications UL 60950-1, CSA C22.2, FCC Class A
Warranty
Product Warranty 2 years
Product Features (0U 15A Series)
Front panel description Rear panel description
B
A
A
B
