CyberPower PDU15SW8FNET User Manual

5
For more information on CyberPower products, visit www.CPSww.com
Product Features (1U 20A Series)
Front panel description
NEMA Type
IEC Type
Rear panel description
A. Power Cord
B. AC Output Outlets
C. Current Level
D. Input Voltage
E. Power
F. Load Indicator
G. Ethernet Port
H. Tx/Rx Indicator
I. Link Indicator
J. Outlet Indicator
(switched series only)
K. Serial/ ENVIROSENSOR Port
(RJ45 modular port)
L. Select Button
M.PDU Status Screen
N. Reset Button
A. External Site Ground
A
A
Technical Specifications
Switched Series (1U 20A) Monitored Series (1U 20A)
Model Name
PDU20SW8FNET
PDU20SWHVIEC8FNET
PDU20M8FNET
PDU20MHVIEC8FNET
PDU20SWT8FNET PDU20MT8FNET
Input
Nominal Voltage 100-120V 200-240V 100-120V 200-240V
Frequency 50/60Hz
Derated Input Current 16A
Plug Type
NEMA 5-20P
IEC-320 C20
NEMA 5-20P
IEC-320 C20
NEMA L5-20P NEMA L5-20P
Power Cord Type SR (12 AWG) Socket SR (12 AWG) Socket
Power Cord Length 12 ft/3.65 m 10 ft/3.05 m 12 ft/3.65 m 10 ft/3.05 m
Output
Nominal Voltage 100-120V 200-240V 100-120V 200-240V
Derated Output Current 16A
Outlet Type NEMA 5-20R IEC-320 C13 NEMA 5-20R IEC-320 C13
Outlet Number 8
Networking
Protocol Support TCP/IP, UDP, DHCP, SNMP, HTTP
Connectivity RJ45
Physical
Dimension (HxWxD) 1.75" x 17.05" x 4.41"/44mm x 433mm x 112mm
Environmental
Humidity 0 to 95% Non-condensing
Altitude 14700 ft/4500 m
Temperature 32
o
F to 104
o
F /0
o
C to 40
o
C
Safety Approvals
Certifications
UL 60950-1
CSA C22.2
FCC Class A
UL 60950-1
CSA C22.2
CE, FCC Class A
UL 60950-1
CSA C22.2
FCC Class A
UL 60950-1
CSA C22.2
CE, FCC Class A
Warranty
Product Warranty 2 years

CyberPower PDU15SW8FNET Specifications

General

Brand	CyberPower
Model	PDU15SW8FNET
Category	Power distribution unit
Language	English
