For more information on CyberPower products, visit www.CPSww.com
Use the provided Cable Ties to fasten each cord to the Cord Retention Tray.
Installation Guide
For 0U Model with Keyhole Mount
Step 1. Keyhole Mount Installation
Use the provided Screws (2) to attach the Keyhole Mounting Pegs (2) to
the PDU.
Step 2. PDU Mounting
Align the Keyhole Mounts to the Keyhole Slots on the rack. Insert and slide
down to lock firmly into the place.
Step 1 – Receptacle evaluation
Ensure that the plug type of your PDU unit matches the wall receptacle
type that you are using.
Step 2 – Plug the PDU into the wall receptacle
The PDU must be plugged into a three-wire, grounded wall
receptacle only. The wall receptacle must also be connected to
an appropriate branch circuit/main with fuse or circuit breaker
protection. Connection to any other type of wall receptacle may
result in a shock hazard.
Electrical Installation
