CYBEX 625T - Page 140

Qty.DescriptionItem
2Deck Bumper1
2Mounting Bolt2
2Washer3
Remove running belt
Remove the running belt from the unit.
NOTE: If the same running belt will be re-installed, note the direction of travel and re-install in
the same direction.
Install running belt
Place the running belt in position on the unit.
Install deck pivot assembly
1. Install the retaining rings, bushings and deck pivot brackets.
Qty.DescriptionItem
2Bolt1
2Split Washer2
2Flat Washer3
2Deck Pivot Bracket4
4Bushing5
2Mounting Bolt6
2Retaining Ring7
1Deck Pivot Shaft8
Page 140 of 209
Cybex 625T Treadmill Part Number
