CYBEX 625T Service Manual

3. Plug RJ45 cable into wireless audio receiver module.
Qty.DescriptionItem
1
Wireless audio receiver
module
1
1RJ45 cable2
1MCC board3
1Audio, gray (J14)4
4. Route RJ45 cable as shown and plug into gray audio connector (J14) on MCC board.
Install headphone jack cable
1. Remove the two screws securing the headphone jack cover to the handset using a Phillips
screwdriver.
Qty.DescriptionItem
1Headphone jack cover1
2Screws2
1Handset3
2. Remove blank decal from headphone jack cover using a utility knife.
3. Install nut into front of headphone jack cover.
Qty.DescriptionItem
1Headphone jack cover1
1Nut2
1Headphone jack cable3
Page 205 of 209
Cybex 625T Treadmill Part Number

CYBEX 625T Specifications

General

User Weight Capacity	400 lbs
Speed Range	0.5 - 12.4 mph
Incline Range	0% to 15%
Display	LED
Heart Rate Monitoring	Contact and wireless
Running Area	60" x 20" (152 x 51 cm)
