CYBEX 770C - Moving the 770 R Unit

Cybex Owner’s Manual
25
Item Quantity Part Number Description
13 4 HS-19108 Screw, 5/16-18 x .75”,HXHD,WHIZ-LOCK,GR5
14 4 HW-53018 Washer, 5/16” Split
15 4 HS-15706 Screw, 8-16 x .50”, PNHD
16 2 HS-18311 Screw, 8-16 x .75”, PNHD
17 4 HS-41107 Screw, 5/16-18 X 1.50”
18 1 HX-00438 3/16” Allen wrench
13 14 157
5
14
3
2
1716 18
1
17
4
16
15
13
15
6
NA
CAUTION: Serious injury or damage to machine can occur. To avoid injury or damage
the following procedure must be followed. Always use proper lifting methods
when moving heavy items.
Lift and move the unit
1. Grasp the rear foot.
2. Lift the rear foot so the front transport wheels are able to roll on oor. Use proper lifting
methods.
3. Roll unit to intended location.
4. Lower the rear foot so unit is in intended location.
