22
Cybex Owner’s Manual
4. Install the left outer rear cover with ve screws using a Phillips screwdriver.
Screws (2)
Screws (3)
Left Outer
Rear Cover
5. Install the left top rear cover with ve screws using a Phillips screwdriver.
Screws (5)
Left Top
Rear Cover
6. Install the left inner and outer collars with two screws using a Phillips screwdriver. Collars are
marked with an “L” on the inside and have a left and right side.
Screws (2)
Left Outer Collar
Left Inner Collar
“L”
