Cybex Owner’s Manual
10.Install the right outer rear cover with ve screws using a Phillips screwdriver.
Screws (3)
Screws (3)
Right Outer
Rear Cover
11.Install the right top rear cover with ve screws using a Phillips screwdriver.
Screws (5)
Right Top
Rear Cover
12.Install the right inner and outer collars with two screws using a Phillips screwdriver. Collars are
marked with an “R” on the inside and have a left and right side.
Screws (2)
Right Outer Collar
Right Inner Collar
“R”
