CYBEX Cloud Q User Manual

8. Press the Belt Tensioning Plate down with both
hands, where indicated, until it locks into place. The
orange Locking Lever will rotate to the
CLOSE
position automatically when the Plate is locked.
If the Belt Tensioning Plate does not lock, try loosening the vehicle
belt slightly.
9. Grab the Base at the Belt Guides and pull from side to side
and front to back to make sure it is installed correctly. The Base
should not move more than 1 inch (2.5 cm) in any direction.
If the Base moves too much, open the Belt Tensioning Plate and
remove a little more slack from the vehicle belt, close Plate and
recheck. After this, if the Base still moves too much, you may need to
try a different vehicle seat location or installation method, or both.
10. Squeeze the Adjustment Handle on the Load Leg
and extend it until the Foot makes rm contact with
vehicle oor. Lock Leg into place using the rst hole
that will rmly lock it against the vehicle oor.
It may be necessary to lift up slightly on the Base to allow the Foot to
lock into the hole. See page 28.
11. Check that the Recline Angle remained in the appropriate
range for the child's weight. If not, remove Base,
adjust recline angle and reinstall. See page 29.
Make sure that vehicle belt buckle and hardware DO NOT INTERFERE
with correct installation of the Base, or with the connection of the
Infant Carrier to the Base.
Automatic
DO NOT turn
35
Use the FIRST hole
that will lock the Load
Leg Foot rmly against
vehicle oor
10
8
9
11
INSTALLING THE BASE USING A LAP BELT ONLY

CYBEX Cloud Q Specifications

General

Certification	ECE R-44/04, Supplement 7
Mounting type	ISOFIX
Product color	Gold
Car seat group	0+ (0 - 13 kg; 0 - 15 months)
Adjustable backrest	Yes
Belt fastening type	5-point

Weight and Dimensions

Depth	665 mm
Width	440 mm
Weight	5400 g
Height (max)	570 mm
Height (min)	403 mm
