Item Qty Part Number Description
1 1 Varies Base with uprights and console attached
5 1 AX-16724 Motor cover, center, with decals
6 1 PL-16465 Motor cover, right (in box)
7 1 PL-16464 Motor cover, left (in box)
NA 1 AX-16956 Hardware pack (in box)
NA 1 LT-16601 TROTTER Elite Manual (in box)
NA 1 LT-16314 Assembly Poster
NOTE: NA means not applicable.
C. Check off ( ✔) each item in the CPA (Cybex Programming Advantage pack as you find it.
See Figure 2.
Cybex TROTTER Elite Treadmill Owner’s & Service Manual
Figure 1
Figure 2
Item Qty Part Number Description
NA 1 LT-16975 CPA Sheet
NA 1 AW-16952 Cable for uploading
CPA program
NA 1 LT-16953 Instructions CPA
Network, TROTTER Elite
NA 1 CN-16927 Adapter, CPA
Setup
&
Assembly
Page 5-3
