D. Check off ( ✔) each item in the hardware pack as you find it. See Figure 3.
Cybex TROTTER Elite Treadmill Owner’s & Service Manual
Hardware - Actual Size
Item Qty Part Number Description
2 8 HS-16929 Screw, hex head whiz-lock 3-8-16 x 5-8
3 2 HS-16950 Screw, button head 5-16-18 x 7-8
4 8 HS-16939 Screw, Phillips head sems 10-32 x .75
8 1 HX-00438 Hex key, 3/16”
Setup
&
Assembly
Page 5-4
