Cyrus 8 DAC - FRONT PANEL PARTS LIST; Front Panel Components; Display PCB

FRONTPANELPARTSLIST
©CyrusAudioLtdJun2014 23 Cyrus6DAC,Cyrus8DACservicemanualIssue1


FrontPanelparts(allmodels)

Ref PartNumber Description
1AM‐POWCP/Standbyknobtrim
2AM‐PLENS/02Powerlens
3AM‐LENSM/02Remoteeyelens
4AM‐DISPW/Displaywindow
5AM‐RKNOB/BVolumecontrolknobplasticinsert
6
AM‐CKNOB/
AM‐CKNOB/S
Volumecontrolknobblack
Volumecontrolknobsilver
7AM‐BPPLT/V0Baseplate
8AM‐BFOOT/Rubberfoot
9
AM‐FACXP/B
AM‐FACXP/S
Frontfaciablack
Frontfaciasilver
10
AM‐FRONT/02
AM‐FRONT/S
Technicalmoulding(blackfrontpanel)
Technicalmoulding(silverfrontpanel)
11
DX‐MBDIS/
DS‐MBDIS/
DisplayPCBincludingLCDwithoutpushcontrol*
DisplayPCBincludingLCDwithpushcontrol*

*Refertopage11toidentifythecorrectpartnumberrequired.
