Cyrus 8 DAC - FRONT PANEL CONTROL PCB; Front panel control PCBs without push control; Front panel control PCBs with push control

FRONTPANELCONTROLPCB
©CyrusAudioLtdJun2014 11 Cyrus6DAC,Cyrus8DACservicemanualIssue1
ThefrontpanelcontrolPCBchangedduringthelifeoftheamplifiers.
ThetwoPCBversionsareeasytoidentifywithoutdismantlingtheamplifier.Therotarycontrol
of the later version display PCB includes a push function, the earlier control PCB does not.
Operationoftheamplifierchangedslightlywiththeintroductionofthepushfunction.
In the event that a front panel control PCB requires replacement, the replacement PCB
suppliedwillbethesametypeastheoriginal.WhenorderingareplacementPCB,alwaysquote
theserialnumberoftheamplifierandstatewhethertherotarycontrolhasapushfunction.
NOTE: The two types of control PCB are not directly interchangeable. To replace an original
'non‐push'type PCBwiththelatertype'push'PCBwouldrequirechangesinothercircuitareas
andalsoupdateduserinstructions.
TheamplifieroperationalsoftwareislocatedonthefrontpanelcontrolPCB.
FrontpanelcontrolPCBswithoutpushcontrol
ReplacementPCBsaresupplied 'clean'ofsoftwaresowhenreplacingthistypeitwillalwaysbe
necessarytoprogramthePCBviatheamplifierprogrammingconnector.
FrontpanelcontrolPCBswithpushcontrol
ReplacementPCBsaresuppliedpre‐programmedsocanbefittedwithoutre‐programmingvia
theamplifier.
Refertopage20formoreinformationaboutprogrammingtheamplifiers.



