Cyrus 8 DAC - MAIN PCB PART LIST; Diodes

MAINPCBPARTLIST
©CyrusAudioLtdJun2014 28 Cyrus6DAC,Cyrus8DACservicemanualIssue1
R470 SMD0603 3k9 MF1/16W1%
R471 SMD0805 1k MF1/8W1%
R474 SMD0603 3k0 MF1/16W1%
R475 SMD0805 1k MF1/8W1%
R476 SMD0805 2k7 MF1/8W1%
R501 SMD0805 47k MF1/8W1%
R502 SMD0805 47k MF1/8W1%
R503 SMD0805 47k MF1/8W1%
R504 SMD0805 1k MF1/8W1%
R505 SMD0805 1k MF1/8W1%
R509 SMD0805 1k MF1/8W1%
R510 SMD0805 100k MF1/8W1%
R515 SMD0805 47k MF1/8W1%
R516 SMD0805 47k MF1/8W1%
R517 SMD0805 47k MF1/8W1%
R518 SMD0805 47k MF1/8W1%
R519 SMD0805 47k MF1/8W1%
R520 SMD0805 0R MF1/8W1% Cyrus6variants
SMD0805 Notfitted Cyrus8variants

Key:MF=metalfilm.NFR=non‐flammableresistor.MRS25=axialmetalfilmresistor
SMD‐0805=referstosurfacemountdevicesizeprofile0805
PRESETS

RV201 100R 150mW10% 
RV202 100R 150mW10% 
RV203 100k 150mW10% 
RV204 100k 150mW10% 
CAPACITORS

C100 SMD0603 100nF CP50V10% X7Rdielectric
C101 SMD0805 100pF CP100V5% NPOdielectric
C102 SMD0805 100pF CP100V5% NPOdielectric
C103 SMD0805 100pF CP100V5% NPOdielectric
C104 SMD0805 100pF CP100V5% NPOdielectric
C105 SMD0805 100pF CP100V5% NPOdielectric
C106 SMD0805 100pF CP100V5% NPOdielectric
C107 SMD0805 100pF CP100V5% NPOdielectric
C108 SMD0805 100pF CP100V5% NPOdielectric
C109 SMD0805 100pF CP100V5% NPOdielectric
C110 SMD0805 100pF CP100V5% NPOdielectric
C111 SMD0805 100pF CP100V5% NPOdielectric
C112 SMD0805 100pF CP100V5% NPOdielectric
C117 SMD0603 100nF CP50V10% X7Rdielectric
C119 RAD0.2W 330pF PP63V5% FKP2
C120 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C121 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C122 RAD0.2W 330pF PP63V5% FKP2
C124 SMD0603 100nF CP50V10% X7Rdielectric
C126 SMD0805 47pF CP50V5% NPOdielectric
C127 SMD0603 100nF CP50V10% X7Rdielectric
C128 SMD0805 47pF CP50V5% NPOdielectric
C130 RAD0.2W 1uF PE63V10% MKS2
C131 RAD0.2W 1uF PE63V10% MKS2
C133 SMD0603 100nF CP50V10% X7Rdielectric
C135 SMD0603 100nF CP50V10% X7Rdielectric
