Cyrus 8 DAC - SUB PCB PART LIST; Resistors (Sub PCB)

MAINPCBPARTLIST
©CyrusAudioLtdJun2014 33 Cyrus6DAC,Cyrus8DACservicemanualIssue1
T229 SC‐74 IMT1A PNP/PNPDualTransistor
T230 SOT23 BC860C PNPSignalTransistor
T235 SOT23 BC860C PNPSignalTransistor
T300 SOT23 BC846C NPNSignalTransistor
T301 SOT223 FZT758 PNPHVTransistorSMT
T302 SOT23 BC856C NPNSignalTransistor
T303 SOT223 FZT658 NPNHVTransistorSMT
T304 SOT23 FMMT593 PNPSignalTransistor
T305 SOT23 FMMT593 PNPSignalTransistor
T306 SOT23 BC860C PNPSignalTransistor
T307 SOT23 BC850C NPNSignalTransistor
T308 SC‐74 IMZ1A NPN/PNPDualTransistor
T309 SC‐74 IMT1A PNP/PNPDualTransistor
T310 SC‐74 IMX1 NPN/NPNDualTransistor
T400 SC‐74 IMX1 NPN/NPNDualTransistor
T401 SOT23 BC846C NPNSignalTransistor
T402 SOT223 2STN2540
PNPCurrentDriver
Transistor

T405 SOT23 BC856C NPNSignalTransistor
T406 SOT223 2STN1360
NPNCurrentDriver
Transistor

T408 SC‐74 IMX1 NPN/NPNDualTransistor
INTEGRATEDCIRCUITS

IC100 SOL‐16 PGA2311UG StereoVolume
IC101 DIP30N SW_LC78211 Inputselecter
IC102 DIP30N SW_LC78211 Inputselecter
IC103 SO‐8 OPA2134UA opamp
IC104 SO‐8 NE5532 opamp
IC200 SO‐8 TL072 opamp
IC201 SO‐8 TL072 opamp
IC402 SO‐8 LM393 Comparator
IC506 SO‐14 74HC14 HexInvertor
VOLTAGEREGULATORS

VR100 SOT‐89 78L05 100mASMD78L00series
VR101 SOT‐89 79L05 100mASMD79L00series
VR401 TO220 7805 1A78seriesreg
VR402 TO220 LM317T 1A78seriesreg
VR403 TO220 LM337T 1A78seriesreg
