SUBPCBPARTLIST
©CyrusAudioLtdJun2014 37 Cyrus6DAC,Cyrus8DACservicemanualIssue1
C814 SMD0603 1nF CP50V5% NPOdielectric
C815 SMD0603 150pF CP100V5% NPOdielectric
C816 SMD0603 150pF CP100V5% NPOdielectric
C817 SMD0603 150pF CP100V5% NPOdielectric
C818 SMD0603 150pF CP100V5% NPOdielectric
C819 SMD0603 33pF CP50V5% NPOdielectric
C820 SMD0603 33pF CP50V5% NPOdielectric
C821 SMD0603 22nF CP50V10% X7Rdielectric
C822 SMD0603 22nF CP50V10% X7Rdielectric
C901 SMD0603 22nF CP50V10% X7Rdielectric
C902 SMD0603 22nF CP50V10% X7Rdielectric
C903 SMD0603 22nF CP50V10% X7Rdielectric
C904 SMD0603 22nF CP50V10% X7Rdielectric
C905 SMD0603 22nF CP50V10% X7Rdielectric
C906 SMD0603 22nF CP50V10% X7Rdielectric
C907 SMD0603 22nF CP50V10% X7Rdielectric
C908 SMD0603 22nF CP50V10% X7Rdielectric
C909 SMD0603 22nF CP50V10% X7Rdielectric
C910 SMD0603 22nF CP50V10% X7Rdielectric
C911 SMD0603 22nF CP50V10% X7Rdielectric
C912 SMD0603 22nF CP50V10% X7Rdielectric
C913 SMD0603 22nF CP50V10% X7Rdielectric
C914 SMD0603 22nF CP50V10% X7Rdielectric
C915 SMD0603 22nF CP50V10% X7Rdielectric
C916 SMD0603 22nF CP50V10% X7Rdielectric
C917 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C919 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C920 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C921 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C922 SMD0603 100nF CP50V10% X7Rdielectric
C923 SMD0603 100nF CP50V10% X7Rdielectric
C926 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C927 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C928 CAPSMD8.0 470uF 16VEL20% EEEFK1C471AP
C929 CAPSMD8.0 470uF 16VEL20% EEEFK1C471AP
C930 RB.3/.6 4700uF 16VEL20% UPS1C472MHD
C931 SMD0603 22nF CP50V10% X7Rdielectric
C932 SMD0603 22nF CP50V10% X7Rdielectric
C933 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR

Key:CP=ceramicplate.EL=electrolytic.PE=polyester.PP=polypropylene.BP=bi‐polar.
CAPSMD6.3referstosurfacemountdevicewith6.3mmpitchpads
SMD‐0805referstosurfacemountdevicesizecode0805
DIODES

D601 SOT23 BZX84‐C3V6
BZX84C3V63V6Zener
Diode

D602 SOT23 BZX84‐C3V6
BZX84C3V63V6Zener
Diode

D603 SOT23 BAV70
DualsignalDiodecommon
cathode

D604 SOT23 BAV70
DualsignalDiodecommon
cathode

D901 DF04S 1A400vSMDBridge
TRANSISTORS

T601 SOT23 BC846C NPNSignalTransistor

