D.A.C.E SPRINT User Manual

10
16VAC
220VAC(frommainssupply)
ELECTRICALWIRING(SPRINT&CONDO)
· The transformer must be plugged into a normalplugsocket inthehouse. 16 VoltsAC is then run
directlyto thePC board16V ACconnection.The distance betweenthetransformer andthe motor
shouldnotexceed50meters.
· Thecableshould berun ina300mmdeeptrenchinawaterproofconduitand must beterminated
insidethemotor.
· Theremustbenojoinsinthecableunderground.
· Thecableshouldbeatwocore1.5mmcable.DO NOT USE COMMUNICATIONCABLE AS THIS
WILLVOIDANYWARRANTYANDISILLEGAL.
NOTE:thetransformermustnotbeopenedinanywayasthismaycauseelectricalshock
Connectfromthetransformer16VoltsACtothe16vAConthemainPCboard.
WIRINGDIAGRAMFROMTRANSFORMERTOCHARGER(SPRINT&CONDO)
ThefollowingsectionexplainshowthewiringshouldbedonefortheCONDOandSPRINTmotors
only.

D.A.C.E SPRINT Specifications

General

Brand	D.A.C.E
Model	SPRINT
Category	Garage Door Opener
Language	English
