Whenanchoringthemotoritisimportanttoens urethatth efollowingpoints arechecked.
· Theelectricalcableisinposition.
· Theconcreteisfullyset.
· Themotorfoundationmountingsaresecureandcannot moveorbecomeloose.
· Themotorshouldbesetlevelandparal leltothegate.
· Themotormustb esetabovethefloodlevelorifthisisnotpossible,af loodproofwallshould
beconstructedaroundthemotor.
Afterplacingthemotoronto
thethreejackupb olts,place
thethreeclampingnutsand
washersovertheboltsto
clampthemotorinplace.
TOPVIEW
Gateinfullyclosedposition
Antiliftdeviceand
Rollers
PCBOARD
Concrete
plinth
8mmCoachscrewsinplugs
PCboard
Jackupnutsfor
adjustingthemotor
height.
SIDEVIEW
ENSURETHATTHEMOTORISMOUNTEDLEVEL
SECURINGTHEMOTORTOTHEFOUNDATIONPLATE
