4

TERMSANDDEFINITIONS

· Autoclose:allowsthegatetocloseautomaticallyafteraselectedtimeperiod.

· Multiusermode:thisisasettingusedintownhousesituationswheretherearemultipletriggers. This

settingwillavoidthemotorgettingmultipletriggersatthesametime.

· Pedestrianaccess:allowsonlypartialopeningofthegate

· Antiliftdevice:stopsthegatebeingliftedofftherail.

· Battery:thebatteryisusedtodrivethemotor.

· SafetyBeams:Thesereducetheriskofthegateclosingonavehicle.Beamsshouldalwaysbeused

whenautocloseisselected.

· Transformer:thetransformerreducesthemainspowerto16VAC.NOTE!Thecableto beusedfrom

thetransformertothemainPCboardmustbeaminimumof1.5mmcable.DONOTuse

communicationscable.

· Chargermodule:theonboardchargerreceives16VACfromthetransformerandthendeliversa

tricklechargetomaintain±13.8VDCchargetothebattery.

· MainPCboard:thisistheprintedcircuitboardthatcontainsalltheelectroniccomponentsthatoper

atethemotor. NOTE! AlwaysremovethepowerfromthePCboardbeforeconnectinganyoutput

wires.

· Remote/Transmitter:thisisusuallyahandheldproductwhichtransmitsaradiosignaltothe

receiver.

· Receiver:thereceivertriggersthemotorafterreceivingaradiosignalfromthetransmitter.

· Testbutton:thisisabuttononthemainPCboardthatcanbeusedtoactivatethemotor.Thisis

usuallyusedduringtheprogrammingofthemotor.

· Rack:thisisalengthoftoothedgearmountedonthegate.

· Piniongear:thisisthegearthatmesheswiththerackinordertodrivethegate.NOTE!Thisisa

serviceablepart.

· Foundationplate:thisisthesteelplatethatismountedtoaconcreteplinthintheground.Themotor is

mountedontothefoundationplateusingthethreemountingbolts.

· Thumb wheel:thisallowsthemotortobeputintoManualOverridemodesothatthegatecanbe

operatedmanuallybyhand.

D.A.C.E SPRINT User Manual
