ANCHORINGTHEMOTOR
Itisveryimportantthatthemotorismountedonafirmfoundationthatcannotmoveorbecomeloose
overtime.Thefoundationshouldbeconstructedfromconcrete.T hesizeoftheplinthshouldbeabout
300by30 0mmsquareandabout200mmdeep.Thefoundationplatesuppliedwiththemot ormustbe
securelymounted totheconcreteusingcoachscrewsandplugs.Thefoundationplatecanalsobe
weldedtothegaterailifneedbe.Theconcreteshouldbeallowedsufficienttimetosetbeforethemo
torismountedontotheplate.
Allowconcretetosetandthenpl acethe
foundationplateontotheconcreteplinth
3
Foundationplate
Placeconcreteplinth here
Placeconcreteplinth here
GATECLOSINGTOTHERIGHT GATECLOSINGTOTHELEFT
2
Placetheconduitinthecorrectpositionbeforef illingthe
holewithconcrete.Flexibleconduitmayalsobeused.
4
Trimtheconduitandthecabletothecorrectlength
beforeplacingthemotorontothefoundationplate.
Use8mmcoachscrewsto
mountthefoundationplate
totheconcrete
Digaholeabout300mm
1
Sideview
Topview
Gate
35m
