VERYIMPORTANT:GEARBOXMUSTBEFILLEDWITHTHESUPPLIEDOILBEFORETHEMOTORIS
OPERATED!
Asshownabove,withthegateintheclosedposition,themagnetmustbemounted700mmfromthe
centreofthemotor.
Ifitisnotpossibletomountthemagnetat700mm,thisdistancemaybee xtendedveryslightly.Themag
netmustnotbeinverted.Ifthemagnetismovedforanyreasonafterthemotorhasbeenprogrammed,
thenthemotorwillhavetobereprogrammed.
MOUNTINGTHEMAGNET
Thegapbetweenthemotorandthemagnet,whenth emagnetpasses themotor,mustnotexceed3mm.
Tocheckthis,manuallymovethegateuntilthemagnet isdirectlyoverthepiniongearthenmeasurebe
tweenthemagnetandthemotorlid.Ifthegapismor ethan3mm,placewashersbehindthemagnetuntil
thecorrectgapisachieved
FILLINGTHEGEARBOXOIL
700mm
Magnet
Placewashershereifgap
isnotcorrect
Maximumgapbetweenthemagnetandthemotor
3mm
Fillthegearboxasshownbellow.Theentire
bottleneedstobeemptiedintothegearbox.
Thegearboxoillevelneedstobecheckedperiodi
cally.Tochecktheoillevel,removetheoillevel
screw.Oilshouldbeaddeduntiltheoiljuststarts
torunoutofthehole.
REPLACETHESCREW!
Oillevelscrew
UseS.A.E.75W/90oiltorefillthegearbox
