2 or 3 haptic actuators:
Captive endings must be installed off-centre from the spacer retainers as follow:
4 haptic actuators:
Captive endings must be installed in the middle of the spacer retainers as follow:
INSTALLATION:
Never operate the haptic actuator without the ending installed. This may lead to irreparable
damages to the actuator:
OUTWARD
OUTWARD
OUTWARD
