D-Link AC1200 - Igmp;Mld

DIR-842V2 AC1200 Wi-Fi Gigabit Router
User Manual
Configuring via Web-based Interface
Page 168
IGMP/MLD
On the Functions/ Advanced / IGMP/MLD page, you can allow the router to use IGMP and
MLD and specify needed settings.
IGMP and MLD are used for managing multicast traffic (transferring data to a group of
destinations) in IPv4 and IPv6 networks correspondingly. These protocols allow using network
resources for some applications, e.g., for streaming video, more efficiently.
Figure 163. The Functions / Advanced / IGMP/MLD page.
The following elements are available on the page:
Parameter Description
IGMP
Enable
Move the switch to the right to enable IGMP.
IGMP version
Select a version of IGMP from the drop-down list.
Interface
From the drop-down list,
select a connection of the Dynamic IPv4 or
Static IPv4 type for which you need to allow multicast traffic (e.g.
streaming video).
MLD
Enable
Move the switch to the right to enable MLD.
MLD version
Select a version of MLD from the drop-down list.
Interface
From the drop-
down list, select a connection of the Dynamic IPv6 or
Static IPv6 type for which you need to allow multicast traffic (e.g.
streaming video).
After specifying the needed parameters, click the APPLY button.
