43D-Link DIR-890L User Manual
Section 4 - Conguration - Router Mode
DS-Lite
DS-Lite is an IPv6 connection type. After selecting DS-Lite, the following parameters will be
available for conguration:
Advanced Settings
DS-Lite
Conguration:
Select DS-Lite DHCPv6 Option to let the router allocate the AFTR
IPv6 address automatically. Select Manual Conguration to enter
the AFTR IPv6 address manually.
DS-Lite DHCPv6
B4 IPv6 Address: Enter the B4 IPv4 address value used here.
WAN IPv6
Address:
Once connected, the WAN IPv6 address will be displayed here.
IPv6 WAN Default
Gateway:
Once connected, the IPv6 WAN default gateway address will be
displayed here.
Manual
AFTR IPv6
Address:
Enter the AFTR IPv6 address used here.
B4 IPv6 Address: Enter the B4 IPv4 address value used here.
WAN IPv6
Address:
Once connected, the WAN IPv6 address is displayed here.
DS-Lite Conguration: Manual Conguration
⌵
AFTR IPv6 Address:
B4 IPv4 Address: 192.0.0.
WAN IPv6 Address: N/A
IPv6 WAN Default Gateway: N/A
COPYRIGHT © 2016 D-Link
DS-Lite Conguration:
DS-Lite DHCPv6 Option
⌵
B4 IPv4 Address: 192.0.0.
WAN IPv6 Address: N/A
IPv6 WAN Default Gateway: N/A
COPYRIGHT © 2016 D-Link
My Internet Connection is: DS-Lite
⌵
DIR-890L HW:A1 FW:1.10
Settings >> Internet
SettingsHome
Internet
Features Management
Use this section to congure your Internet Connection type. There are several connection types to choose
from Static IP, DHCP, PPPoE, PPTP, L2TP and DS-Lite. If you are unsure of your connection method, please
contact your Internet service provider. Note: If using the PPPoE option, you will need to remove or disable
any PPPoE client software on your computers.
Advanced Settings ...
IPv6
Save
Device Mode:
Router Mode
⌵
COPYRIGHT © 2016 D-Link
Device Mode: Router Mode
My Internet
Connection Is:
DS-Lite
