D-Link DAP-1330 User Manual

7D-Link DAP-1330 User Manual
Section 1 - Product Overview
The Status/WPS LED will turn solid green when the DAP-1330 has connected successfully to an uplink wireless network and is
extending that network. If the Signal Indicator LED has a single amber bar after the connection process has nished, the DAP-1330
has established a poor quality connection. The more lit bars on the Signal Indicator LED, the better the wireless signal. To improve
the connection quality, the DAP-1330 should be relocated closer to the source wireless router.
Poor Ok Good Best
Wireless Signal Strength Indicator LED

D-Link DAP-1330 Specifications

General

Product color	White
LED indicators	Yes
Maximum data transfer rate	100 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u
Interface	Wi-Fi/Ethernet
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA, WPA2, WPS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating altitude	5 - 95 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, IC, CE, C-Tick, CB, UL

Weight and Dimensions

Weight	86.9 g
Dimensions (WxDxH)	77 x 55.5 x 34 mm
