D-Link DAP-1330 User Manual

11D-Link DAP-1330 User Manual
Section 2 - Installation
Move the antennas to their upward
position before plugging in the
extender.
Position Antennas
Locate your DAP-1330 to an area which
you wish to extend Wi-Fi to.
Find a location
Plug in the DAP-1330 to an outlet or
power strip. The WPS/Status LED will
immediately activate to indicate the
device is booting up.
Plug-in Extender
Hardware Setup
Outlet

D-Link DAP-1330 Specifications

General

Product color	White
LED indicators	Yes
Maximum data transfer rate	100 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u
Interface	Wi-Fi/Ethernet
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA, WPA2, WPS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating altitude	5 - 95 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, IC, CE, C-Tick, CB, UL

Weight and Dimensions

Weight	86.9 g
Dimensions (WxDxH)	77 x 55.5 x 34 mm
