D-Link DAP-1330 User Manual

5D-Link DAP-1330 User Manual
Section 1 - Product Overview
Hardware Overview
Front
1
2
3
1 Status/WPS LED This LED indicates the current status of the DAP-1330, as detailed on the next page.
2 WPS Button
Press to establish a connection with another WPS compatible device. Pressing the WPS button for 1 second allows you to
connect with Wi-Fi clients using Wi-Fi Protected Setup. Refer to “WPS-PBC Configuration” on page 13 for more information.
3
Signal Indicator
LED
The more lit green bars on the Signal Indicator LED, the better the wireless signal to the host network. A single
solid amber LED indicates a weak Wi-Fi signal. Refer to “Wireless Signal Strength Indicator LED” on page 7.

D-Link DAP-1330 Specifications

General

Product color	White
LED indicators	Yes
Maximum data transfer rate	100 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u
Interface	Wi-Fi/Ethernet
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA, WPA2, WPS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating altitude	5 - 95 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, IC, CE, C-Tick, CB, UL

Weight and Dimensions

Weight	86.9 g
Dimensions (WxDxH)	77 x 55.5 x 34 mm
