D-Link DAP-X1860 User Manual

7D-Link DAP-X1860 User Manual
Section 1 - Product Overview
Left Side
1 Reset Button
Use an unfolded paperclip to press and hold the reset button on the bottom of DAP-X1860 for 10 seconds
to restore to factory default settings.
2 WPS Button Press to establish a connection with another WPS compatible device.
3 LAN Connect an Ethernet cable if you are adding wireless to wired network.
2
1
3

D-Link DAP-X1860 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	100, 1000 Mbit/s
Maximum transfer distance	185 m
Modulation	OFDM, QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Security algorithms	WPA2, WPA3
Wi-Fi data rate (max)	1200 Mbit/s
Certification	FCC, IC, CE
Mounting type	Wall
Product color	White
Ethernet LAN (RJ-45) ports	1
Antenna type	Internal
Antennas quantity	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	9.7 W
Included power plug types	EU
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage temperature (transmitter)	5 - 95 °C
Operating temperature (transmitter)	10 - 90 °C
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	75 mm
Width	60 mm
Height	165 mm
Weight	293 g
