Section 3 - Conguration
Wireless Setup Wizard
To access the setup utility for the DAP-X1860
AX1800 Mesh Wi-Fi 6 Range Extender on your PC, rst connect to the DAP-X1860
wirelessly using the Wi-Fi name (SSID) and password located on the back of your
DAP-X1860. Then open a web browser and enter http://dlinkap.local./ in your
browser’s URL eld. You may also enter the IP address* of the DAP-X1860.
* The default IP address is 192.168.0.50. Once your DAP-X1860 connects to the host network,
it will be assigned a new IP address based on your network’s DHCP settings. You will need
to log in to your router to see what IP address is assigned to your DAP-X1860. For multiple
DAP-X1860s, go to http://dlinkapxxxx.local. as shown on the included Quick Installation
Card, with “xxxx” being the last four digits of the DAP-X1860’s MAC address.
If this is your rst time logging in to the extender and no connection has been
established, the setup wizard will automatically appear. If the setup process was
not previously completed, then log in to the interface by leaving the password
eld blank.
The setup wizard is designed to guide you through a step-by-step process to congure your new DAP-X1860
AX1800 Mesh Wi-Fi 6 Range Extender to extend your wireless network and connect to the Internet via a wireless setup process. To
set your DAP-X1860 using an Ethernet cable, please refer to “Access Point Mode Settings” on page 23.

D-Link DAP-X1860 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	100, 1000 Mbit/s
Maximum transfer distance	185 m
Modulation	OFDM, QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Security algorithms	WPA2, WPA3
Wi-Fi data rate (max)	1200 Mbit/s
Certification	FCC, IC, CE
Mounting type	Wall
Product color	White
Ethernet LAN (RJ-45) ports	1
Antenna type	Internal
Antennas quantity	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	9.7 W
Included power plug types	EU
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage temperature (transmitter)	5 - 95 °C
Operating temperature (transmitter)	10 - 90 °C
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	75 mm
Width	60 mm
Height	165 mm
Weight	293 g
