D-Link DAP-X1860 User Manual

4D-Link DAP-X1860 User Manual
Section 1 - Product Overview
What is a Wireless Extender?
The DAP-X1860 acts as a repeater to extend the range of an existing wireless network to provide a better signal for parts of your
home or oce that may have poor or no reception. Your existing wireless signal will be re-broadcast by the DAP-X1860, allowing
you to reach the farthest corners of your home or oce. The extended network can simply use the same network credentials as the
existing network, or you can specify a dierent network name and password, giving you the exibility to control network access.
You may also use the DAP-X1860 as a wireless access point by connecting an Ethernet cable.
Extend Your Wireless Network using Wi-Fi
Extend Your Wireless Network using Ethernet
Router
Internet
DAP-X1860 Wireless Devices
Router DAP-X1860
Internet
Wireless Devices

D-Link DAP-X1860 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	100, 1000 Mbit/s
Maximum transfer distance	185 m
Modulation	OFDM, QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Security algorithms	WPA2, WPA3
Wi-Fi data rate (max)	1200 Mbit/s
Certification	FCC, IC, CE
Mounting type	Wall
Product color	White
Ethernet LAN (RJ-45) ports	1
Antenna type	Internal
Antennas quantity	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	9.7 W
Included power plug types	EU
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage temperature (transmitter)	5 - 95 °C
Operating temperature (transmitter)	10 - 90 °C
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	75 mm
Width	60 mm
Height	165 mm
Weight	293 g
