9D-Link DCS-2332L User Manual
Section 1: Product Overview
Rear: External
1 Weatherproof Cover Weatherproof protective panel
2 Protective Cable Cover Weatherproof cable connection cover
3 Ethernet Cable
RJ-45 Ethernet cable to connect to your network
4 Speaker Audio output
5 Weatherproof Cover Weatherproof cover for the microSD Card slot and reset button
6 Weatherproof Screw Covering Weatherproof protective covering for enclosure screws
7 Power Cable
Connected to the included DC 5V power adapter
8 WPS Button
Press this button and then press the WPS button for ve seconds on
your router to set up a wireless connection automatically
9 Adjustment Ring Tighten or loosen the adjustment ring to adjust the camera's position
