D-Link DES-3350SR - Section 11 Maintenance; TFTP Utilities

D-Link DES-3350SR Standalone Layer 3 Switch
130
default value is one second.
Record Number [200]
Select number of times the Switch will be
polled between 20 and 200. The default
value is 200.
Utilization
Check whether or not to display Utilization.
Port Utilization
The Utilization window shows the percentage of the total available bandwidth being used on the port.
To view port utilization, click on the Monitoring folder and then the Port Utilization link:
Figure 10 - 2. Utilization window
Click the port on the front panel display that you want to display port utilization.
The following fields can be set:
Parameter Description
Time Interval [1s ] Select the desired setting between 1s and 60s,
where “s” stands for seconds. The default
value is one second.
Record Number [200] Select number of times the Switch will be
polled between 20 and 200. The default value
is 20.
Show/Hide
Check to display Utilization.
Clear
Clicking this button clears all statistics
counters on this window.
Packets
The Web Manager allows various packet statistics to be viewed as either a line graph or a table. Six windows are offered.
